MIL-DTL-24487B (SH)
ASTM D 792 - Standard Test Methods for Density and Specific Gravity (Relative Density) of Plastics by
Displacement. (DoD adopted)
ASTM D 2240 - Standard Test Method for Rubber Property - Durometer Hardness. (DoD adopted)
(Copies of these documents are available from www.astm.org or ASTM International, 100 Barr Harbor
Drive, West Conshohocken, PA 19428-2959.)
THE SOCIETY FOR PROTECTIVE COATINGS
SSPC-SP 10 - Near-White Blast Cleaning
(Copies of this documents are available from www.sspc.org or SSPC: The Society for Protective Coatings,
40 24 Street, 6th Floor, Pittsburgh, PA 15222-4656)
th
2.4 Order of precedence. In the event of a conflict between the text of this document and the references
cited herein, the text of this document takes precedence. Nothing in this document, however, supersedes applicable
laws and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 First article. When specified (see 6.2), a sample shall be subjected to first article inspection in
accordance with 4.2.
3.2 Rubber properties. The rubber in Class 1 and 2 tiles shall have the properties listed in Table I.
Formulations of rubber compounds which have been found to have these properties are given in 6.3.
3.2.1 Toxicity. When evaluated in accordance with 4.5.9, the vibration damping tiles shall have no
adverse effect on the health of personnel when used for its intended purpose and shall not cause any environmental
problems during waste disposal (see 4.5.9 and 6.5).
3.2.2 Off-gassing. The vibration damping tiles shall meet the requirements in the Nuclear Powered
Submarine Atmosphere Control Manual, NAVSEA Technical Manual S9510-AB-ATM-010 Rev. 2, for a usage
category of Limited (see 4.5.10 and 6.6).
TABLE I. Physical properties of rubber.
Properties
Class 1
Class 2
Initial properties:
Specific gravity
Compare to first article value
Compare to first article value
Hardness, durometer points
(See 4.5.3.1)
(See 4.5.3.1)
Tensile strength, lb/in2 (kPa), min
960 (46.0)
1350 (64.6)
Ultimate elongation, percent, min
500
500
Properties after aging in oven:
Tensile strength, percent of initial, min
85
85
Ultimate elongation, percent of initial, min
70
70
Properties after immersion in water:
Volume change, percent, max
15
15
Adhesion to painted steel, inches (cm)
stripped per hour, max
1 (2.5)
1 (2.5)
3
