A-A-55762A
030-B-5
0.562
0.562
144.0
45.0 - 55.0
700
-100 to 425
031-E-5
0.750
0.250
72.0
45.0 - 55.0
1200
-100 to 425
032-E-3
0.750
5.000
1200.0
20.0 - 35.0
850
-130 to 400
034-F-6
4.000
0.063
8.0
55.0 - 65.0
1200
-94 to 400
035-B-5
0.730
0.078
5.7
45.0 - 55.0
700
-100 to 425
***036-F-3
0.080
0.375
180.0
25.0 - 35.0
1000
-94 to 400
* Grades 40 to 70 acceptable.
** Special features: 0.120 in X 45° chamfer on 4 corners.
*** Unless otherwise specified, color should be gray.
Notes: 1.
Unless otherwise noted, dimensions are in inches.
2.
NHR: Nonmetallic hardness rating, Shore Durometer A.
3.
Minimum tensile strength in pounds per square inch.
4.
Surface condition: Smooth both sides.
5.
A/A Any acceptable.
3.2 Material. Material shall be silicone rubber formulated and processed to meet the physical and
mechanical properties per the specified class and grade, when tested in accordance with ASTM
test methods specified in Table I of CID A-A-59588.
3.3 Color. Unless otherwise specified, the color of the silicone rubber shall be the natural color of
the compound furnished.
3.4 Workmanship. The end product shall be clean, smooth finished, and free from dirt, flash or
rough edges.
3.5 Marking. Unless otherwise specified (see ordering data), sheet material and strips (cut from
sheet) shall be marked with the following information: Basic CID number, class, grade,
designations, and the supplier's designations. The class and grade designations separated by a
dash, shall be enclosed within parentheses. The markings shall be legible and placed in rows of
constantly 5 inches apart. The supplier's designation (compound number) shall appear
immediately below the constantly recurring description symbols. The symbols shall be legible and
shall be not less than 3/8 inches high. The symbols shall be applied by suitable means, using a
black colored marking fluid to mark white colored silicones and a white colored marking fluid to
mark other than white colored silicones. The marking shall not be obliterated by normal handling or
by the action of petroleum-based oils.
3.6 Metric products. Products manufactured to metric dimensions will be considered on an equal
basis with those manufactured using inch-pound units, provided they fall within specified tolerances
using conversion tables contained in the latest revision of ASTM SI 10, and all other requirements
of this commercial item description are met. If a product is manufactured to metric dimensions and
those dimensions exceed the tolerances specified in the inch-pound units, a request should be
made to the contracting officer to determine if the product is acceptable.
4. REGULATORY REQUIREMENTS. The offeror/contractor is encouraged to use recovered
materials to the maximum extent practicable, in accordance with paragraph 23.403 of the Federal
Acquisition Regulation (FAR).
5. PRODUCT CONFORMANCE.
5.1 Product conformance. The products provided shall meet the salient characteristics of this
commercial item description, conform to the producer's own drawings, specifications, standards,
and quality assurance practices, and be the same product offered for sale in the commercial
market. The government reserves the right to require proof of such conformance.
6. PACKAGING. Preservation, packing, and marking shall be as specified in the contract or order.
3
