A-A-55762A
3. SALIENT CHARACTERISTICS.
3.1 Dimensional and physical requirements. Dimensional and physical requirements shall conform
to figure 1. Dimensional tolerance shall conform to the applicable commercial tolerance specified in
CID A-A-59588.
Figure 1. Dimensional and physical requirements.
Table I. Dash sizes and dimensions.
MIN TENSILE
DASH
A
B
C
NHR
STRENGTH
TEMP
SIZE
WIDTH
HEIGHT
LENGTH MIN
MAX
P.S.I
RATING ºF
001-C-5
0.015
0.400
9.8
45.0 - 55.0
700
-80 to 425
002-D-7
0.032
1.500
15.0
65.0 - 75.0
650
-80 to 425
003-A-5
0.031
2.000
3.0
45.0 - 55.0
700
-100 to 425
004-C-6
0.031
2.000
6.0
55.0 - 65.0
650
-80 to 425
005-C-5
0.047
0.750
25.0
45.0 - 55.0
700
-80 to 425
006-C-5
0.047
0.750
27.0
45.0 - 55.0
700
-80 to 425
007-C-5
0.047
0.750
73.0
45.0 - 55.0
700
-80 to 425
008-C-5
0.047
0.750
130.0
45.0 - 55.0
700
-80 to 425
009-C-5
0.750
0.750
198.0
45.0 - 55.0
700
-80 to 425
010-C-5
0.062
1.500
144.0
45.0 - 55.0
700
-80 to 425
011-D-4
0.062
3.000
6.0
35.0 - 45.0
700
-100 to 425
012-C-5
0.062
4.000
72.5
45.0 - 55.0
700
-80 to 425
013-B-*
0.090
0.500
1.5
35.0 - 75.0
600
-100 to 425
014-A-4
0.090
0.880
1.6
35.0 - 45.0
700
-100 to 425
015-C-5
0.090
1.880
13.5
45.0 - 55.0
700
-80 to 425
016-D-5
0.093
0.250
A/A
45.0 - 55.0
700
-80 to 425
017-A-4
0.125
0.550
6.6
35.0 - 55.0
700
-100 to 425
018-C-5
0.125
0.500
19.0
45.0 - 55.0
700
-80 to 425
019-D-4
0.125
0.500
54.3
35.0 - 45.0
700
-80 to 425
020-D-4
0.125
1.000
56.6
35.0 - 45.0
700
-80 to 425
021-D-4
0.125
1.000
63.3
35.0 - 45.0
700
-80 to 425
022-C-5
0.125
1.062
144.0
45.0 - 55.0
700
-80 to 425
023-F-3
0.250
0.500
66.0
25.0 - 35.0
1000
-94 to 400
**024-C-8
0.250
0.910
10.2
75.0 - 85.0
500
-100 to 425
025-C-5
0.250
2.000
34.2
45.0 - 55.0
700
-80 to 425
026-D-6
0.250
5.000
80.3
55.0 - 65.0
650
-80 to 425
027-C-5
0.375
0.625
A/A
45.0 - 55.0
700
-80 to 425
028-C-5
0.375
1.250
25.3
45.0 - 55.0
700
-80 to 425
029-D-4
0.375
2.000
14.3
35.0 - 45.0
700
-80 to 425
2
