MIL-PRF-20092M
(m) Material safety data sheet (MSDS) requirements (see 6.4).
6.3 Design information. Unless a particular type of cellular material is specifically desired, the type
should not be specified. The approximate compressibility and density should be determined and detail drawings
and specifications should designate the material by indentation, of compression resistance and density required.
Table IV reflects a comparison of compression resistance measured in terms of 50 in2 square inches with
corresponding densities obtainable in uncored material.
TABLE IV. Comparison of compression resistance.
Mattress inserts
Cushioning material
Indentation
Compression resistance 1/
Apparent
Apparent density
density
(max)
lb/ft3
(max)
lb/ft3
Class
Condition
Pounds
Pounds
Class 5
Medium
25 to 42
8.0
25 to 42
8.0
Medium firm
30 to 55
9.0
30 to 55
9.0
Firm
42 to 60
9.2
42 to 60
9.2
Soft
N/A
N/A
10 to 25
7.5
1/ The compression resistance for Type II material is based upon a maximum sample thickness of 1.125
inches (see 4.5.3). Material which is being acquired at a thickness exceeding 1.125 inches will possess a
condition somewhat more firm than that indicated by its compression resistance value. Acquisition documents
should specify the condition accordingly.
6.4 Material safety data sheets. Contracting officers will identify those activities requiring copies of
completed Material Safety Data Sheets prepared in accordance with FED-STD-313. In order to obtain the MSDS,
FAR clause 52.223-3 must be in the contract.
6.5 Off-gassing. Materials to be installed in submarines are to be controlled to prevent off-gassing,
which contaminates the atmosphere and results in health hazards to personnel or deleterious effects on machinery.
These controls are accomplished through the Submarine Material Control Program, which is described in the
Nuclear Powered Submarine Atmosphere Control Manual, NAVSEA Technical Manual S9510-AB-ATM-010/(U).
Under the Submarine Material Control Program, all materials considered for use on submarines require
certification and assignment of a usage category. Under the certification process, candidate materials are selected
by Navy activities or contractors, and a request for certification is submitted to Commander, Naval Sea Systems
Command, ATTN: SEA 05Z9, 1333 Isaac Hull Ave., SE, Stop 5122, Washington Navy Yard DC 20376-5122. The
certification request is accompanied by detailed information, including descriptions of the material. A chemical
analysis is conducted, which is normally accomplished through off-gas testing. The off-gas test is required to be
conducted in a Government approved laboratory designated by the preparing activity. Information pertaining to this
test requirement may be obtained from Commander, Naval Sea Systems Command, ATTN: SEA 05Z9, 1333 Isaac
Hull Ave., SE, Stop 5160, Washington Navy Yard, DC 20376-5160. Based on the chemical analysis results, a
usage category is assigned to the material defining whether, and to what extent, the material may be used on
submarines.
6.6 Toxicity evaluation. The NAVENVIRHLTHCEN requires sufficient information to permit a HHA of
the product. Any questions concerning toxicity and requests for HHA should be addressed to the Commanding
Officer, Navy Environmental Health Center, ATTN: Hazardous Materials Department, Industrial Hygiene
Directorate, 620 John Paul Jones Circle, Suite 1100, Portsmouth, VA 20378-2103. Upon receipt of the HHA, a
copy should be provided to Commander, Naval Sea Systems Command, ATTN: SEA 05Z9, 1333 Isaac Hull Ave.,
SE, Stop 5133, Washington Navy Yard, DC 20376-5160.
12
