A-A-55760A
3. SALIENT CHARACTERISTICS.
3.1 Dimensional and physical requirements. Dimensional and physical requirements shall conform
to figure 1. Dimensional tolerance shall conform to the applicable commercial tolerance specified in
CID A-A-59588.
.060
48.00
1.000
Figure 1 Dimensional and Physical
Requirements.
Notes: 1.
Dimensions are in inches.
2.
Strengthening feature: Backing.
3.
External strengthening feature location: One side.
4.
Strengthening feature material: Polytetrafluoroethylene.
5.
Fabrication method: Solid.
6.
Surface condition: Smooth.
3.2 Material. Material shall be silicone rubber formulated and processed to meet the physical and
mechanical properties per the specified class and grade, when tested in accordance with ASTM
test methods specified in Table I of CID A-A-59588.
3.3 Color. Unless otherwise specified, the color of the silicone rubber shall be the natural color of
the compound furnished.
3.4 Workmanship. The end product shall be clean, smooth finished, and free from dirt, flash or
rough edges.
3.5 Marking. Unless otherwise specified (see ordering data), sheet material and strips (cut from
sheet) shall be marked with the following information: Basic CID number, class, grade,
designations, and the supplier's designations. The class and grade designations separated by a
dash, shall be enclosed within parentheses. The markings shall be legible and placed in rows of
constantly 5 inches apart. The supplier's designation (compound number) shall appear
immediately below the constantly recurring description symbols. The symbols shall be legible and
shall be not less than 3/8 inches high. The symbols shall be applied by suitable means, using a
black colored marking fluid to mark white colored silicones and a white colored marking fluid to
mark other than white colored silicones. The marking shall not be obliterated by normal handling or
by the action of petroleum-based oils.
2
